Precision Torque Measurement
Torque Sensor Solutions for Demanding Test Work
Reaction, rotary transformer, slip ring and true wireless models. Standard or custom built, calibrated in house, and fatigue rated for life testing.
- Capacities from 50 oz-in to 1,000K lb-in
- Speeds up to 35,000 rpm with high stiffness, low inertia
- Custom designs engineered and built in Shelby Township, MI
Designing and building force and torque sensors since 1993.
Prefer to talk? Call +1 (586) 739-4254
Request Torque Sensor Pricing
Tell us about your test setup. An engineer will help you match the right model or design a custom one.
Why engineers choose SensorData torque sensors
A model for every drive type
Reaction, rotary transformer, slip ring and true wireless Bluetooth versions. Flange, shaft, spline, sprocket and pulley drives are all available.
Built for fatigue and life testing
Fatigue rated construction stands up to life testing and test-to-failure work on drive-line components.
Accurate under real test loads
High torsional stiffness and low inertia keep readings clean. Accuracy runs from 0.1% to 1% depending on the model.
Custom when the catalog will not do
We design, engineer and manufacture in house, so special capacities, shafts and packages are straightforward.
Calibration included with our electronics
In-house calibration is free with SensorData electronics, or available for a fee with your own electronics.
Stand behind every standard sensor
All standard sensors carry a 100% satisfaction guarantee with a 60-day return policy.
Torque sensor models and specifications
Our torque sensor line covers static reaction measurement and rotating shaft measurement. Signal transfer options include rotary transformer (non-contact), slip ring, and true wireless Bluetooth at 2.4 GHz. Most bodies are machined from SAE 4340 alloy steel with a satin nickel finish.
If you also measure axial load or need torque plus thrust in one package, our multi-axis sensors handle both axes with less than 2% crosstalk. Tell us the capacity, speed and mounting, and we will point you to the right model or quote a custom design.
- Capacity range: 50 oz-in to 1,000K lb-in across the product line
- Speed ratings up to 35,000 rpm (T258) and 20,000 rpm (T259)
- T258 meets Army-Navy standards AND 20002 and AND 10262
- T171-231 dual range reaction sensor with TEDS per IEEE 1451.4, ranges 5/20 to 500/1.5K lb-ft and ±10 VDC output
- SYNTH true wireless sensors transmit over 500 feet and are intrinsically safe in ZONE1 DIV 1 areas
- BT4000 flange driver sends 16-bit data up to 100 feet, immune to EMI and ground loops
- T360 series capacities from 150 to 500K lb-in, compatible with AC or DC electronics
- Options include zero velocity speed sensor, angle encoder, on-board shunt calibration and TEDS chips
- Works with AC carrier or DC strain gage signal conditioning, including our i200 electronics
Trusted in labs and on test stands
“I am happy to say the results so far are quite good and we are happy with the T-123 sensor - the data is very repeatable for different runs under the same rotation conditions”
“We have extensively been using your T123 sensors on our experiments. There are many things we learned from our measurement campaigns, and we are quite happy with the choice. The zero stability and repeatability of the data from the T123 sensors are extremely good, and gave us real confidence on the quality of the results.”
“Thank you very much! You were extremely helpful and responsive in a short amount of time. I believe we'll be doing business down the road. Thanks again”
What happens after you send your request
Share your application
Send capacity, speed, mounting and the kind of test you run. A short note is enough to start.
Talk with an engineer
Free consultation to match a standard model or scope a custom sensor for your setup.
Get a written quote
You receive pricing, specs and a delivery schedule, plus cable and connector options.
Frequently asked questions
How much does a torque sensor cost?
Pricing is quote based. Cost depends on capacity, drive type, speed rating, signal method and any options such as a speed sensor or TEDS. Send your specs and we will price it.
Can you build a custom torque sensor?
Yes. We design, engineer and manufacture custom sensors in house, including non-standard capacities and configurations. Engineering consultation is part of the process.
Do I need separate electronics?
Most models work with AC carrier or DC strain gage signal conditioning, such as our i200. The T171-231 has proprietary on-board electronics with a ±10 VDC output.
Is calibration included?
In-house calibration is free when used with SensorData electronics. If you supply your own electronics, calibration is available for a fee. We also issue calibration certificates with traceable data.
Can a torque sensor work without cables?
Yes. SYNTH true wireless sensors transmit over 500 feet on 2.4 GHz Bluetooth, and the BT4000 flange driver transmits up to 100 feet. Both avoid cable runs and are immune to EMI.
Do you ship outside the United States?
Yes. We sell across the United States and internationally, including Europe and other global markets.
Get the right torque sensor for your test
Send your capacity, speed and mounting details. An engineer will review your application and send a quote with specs and delivery.
- Capacities from 50 oz-in to 1,000K lb-in
- Speeds up to 35,000 rpm with high stiffness, low inertia
- Custom designs engineered and built in Shelby Township, MI
Prefer to talk? Call +1 (586) 739-4254
