Turnkey force & torque measurement
Test & Measurement Systems Built Around Your Test Rig
Sensors, signal conditioning and data software, engineered and calibrated in house. Tell us what you need to measure and we will quote the right setup.
- Force, torque and multi-axis sensors matched to your test
- Wireless load monitoring with real-time data and archiving
- Custom systems designed, built and calibrated in house
Force and torque measurement systems designed and built in Michigan since 1993.
Prefer to talk? Call +1 (586) 739-4254
Get your system quote
Tell us what you measure and an engineer will spec the system.
Why engineers choose SensorData
One source for the whole system
Sensors, signal conditioning electronics and data acquisition software come from one team, so the parts work together.
Fatigue rated for life testing
Our fatigue rated load cells are guaranteed against fatigue failure for 100 million fully reversed cycles.
Wireless where cables fail
True Bluetooth and 915 MHz options send data without cabling and stay immune to EMI, ground loops and nearby metal.
Built to your spec
We design, engineer and manufacture custom sensors and complete measurement systems in house for non-standard jobs.
Calibration and certificates
In-house calibration and recalibration with certification. Free with SensorData electronics, or for a fee with your own.
Backed by a guarantee
100% satisfaction guarantee on standard sensors with a 60-day return policy and warranty options.
What goes into your measurement system
A test and measurement system is more than a sensor. You need the right transducer for the load or torque, electronics that condition the signal, and software that shows and stores the data. We build all three and match them to your application.
For load monitoring in the field, our wireless systems drop in and send real-time data to a base station and PC. The patented conveyor diagnostic system is one example, reading four components of load at once for predictive wear analysis.
- Fatigue rated shear web and pancake load cells in capacities from 200 lb to 500K lb
- Compression, general purpose and hydraulic actuator force sensors, accuracy to 0.07%
- Torque sensors from 50 oz-in to 1,000K lb-in: reaction, rotary transformer, slip ring or wireless
- High-speed rotary torque measurement up to 35,000 rpm (Model T258)
- Multi-axis torque and thrust or X-Y force sensors with crosstalk under 2% and under 0.5%
- Patented conveyor system measures Fz, Mx, My and Mz and transmits wirelessly up to 750 feet
- SYNTH wireless Bluetooth torque sensors transmit over 500 feet and ship with LabVIEW software
- i200 AC carrier signal conditioning and i100 bridge simulator with 0.03% accuracy for checkout
Field proven measurement, test after test
“I am happy to say the results so far are quite good and we are happy with the T-123 sensor - the data is very repeatable for different runs under the same rotation conditions”
“Thank you very much! You were extremely helpful and responsive in a short amount of time. I believe we'll be doing business down the road. Thanks again”
“We have extensively been using your T123 sensors on our experiments. There are many things we learned from our measurement campaigns, and we are quite happy with the choice. The zero stability and repeatability of the data from the T123 sensors are extremely good, and gave us real confidence on the quality of the results.”
How it works
Tell us your test
Send your loads, speeds, space limits and the data you need. Use the form and an engineer reads it.
Free consultation
We recommend a standard sensor or a custom design, plus the electronics and software to go with it.
Quote and delivery
You get pricing and a delivery schedule we commit to, with calibration and certification included as quoted.
Frequently asked questions
How much does a test and measurement system cost?
Pricing is quote based, not off the shelf. Cost depends on capacity, number of axes, wireless or wired signal, electronics and software. Send your details and we will price the exact setup.
Can you build a system for an unusual application?
Yes. We offer custom sensor design, engineering and manufacturing, plus complete custom measurement system development that integrates sensors, electronics, signal conditioning and data acquisition.
Do you calibrate the sensors and supply certificates?
Yes. We calibrate and recalibrate in house and issue calibration certificates with traceable data. Calibration is free with SensorData electronics, or available for a fee with customer-supplied electronics.
What if the sensor is not right for our test?
Standard sensors carry a 100% satisfaction guarantee with a 60-day return policy. Warranty options include free repair or a replacement part at our discretion, and free calibration on certain models for the first four years.
Can we monitor loads without running cables?
Yes. Our patented conveyor diagnostic system transmits real time data up to 750 feet at 915 MHz, SYNTH wireless torque sensors transmit over 500 feet, and the BT4000 flange driver works up to 100 feet.
Do you ship outside the United States?
Yes. We sell across the United States and internationally, including Europe. Standard and custom turnkey systems reach customers anywhere in the nation or across the world.
Get a system spec'd for your test
Share your loads, speeds and data needs. An engineer will recommend the sensors, electronics and software, then send pricing and a delivery schedule.
